Verified by ANSI/BHMA
> Material:SPCC
> Material thickness:1.2x1.2x1.2mm
> Dynamic load capacity:75lb
> Drawer quick disconnection
> Finish: Clear Zinc or Black Electrophoresis
Item No. | Nominal length NL(mm) | Travel length (mm) |
A (mm) |
B (mm) |
C (mm) |
D (mm) |
E (mm) |
F (mm) |
G (mm) |
H (mm) |
B3503-10 | 250(10") | 250(10") | 64 | - | - | 160 | - | - | - | 160 |
B3503-12 | 300(12") | 300(12") | 64 | - | - | 208 | 96 | - | - | 192 |
B3503-14 | 350(14") | 350(14") | 96 | - | - | 256 | 96 | - | 192 | 256 |
B3503-16 | 400(16") | 400(16") | 96 | - | - | 288 | 96 | - | 192 | 288 |
B3503-18 | 450(18") | 450(18") | 96 | 144 | - | 352 | 96 | 192 | - | 352 |
B3503-20 | 500(20") | 500(20") | 96 | 192 | - | 384 | 96 | 192 | 288 | 416 |
B3503-22 | 550(22") | 550(22") | 96 | 192 | 320 | 448 | 96 | 192 | 320 | 448 |
